EMC Test

PRE-COMPLIANCE & TESTING

Mobirise

Esd GENERATOR

In our internal laboratory we can carry out EMC Pre-Compliance tests, performed with the AMETEK Dito ESD simulator.
For tests according to Bellcore GR-1089-Core, Chrysler PF-9326,
DaimlerChrysler PF-10540, EN 300329, EN 300340, EN 300342-1,
EN 300386 V1.3.2, EN 301489-1, EN 301489-17, EN 301489-24, EN 301489-7,
EN 55024, EN 61000-4-2, Fiat 9.90110, Ford EMC-CS-2009.1,
Ford ES-XW7T-1A278-AB,Ford ES-XW7T-1A278-AC, Ford WDR 00.00EA,
IEC 61000-4-2, IEC 61326, ISO 10605, ITU-T K.20, ITU-T K.21, ITU-T K.45,
JASO D001-94, MIL STD 461 G CS 118, Renault 36.00.400 / B, Renault 36.00.400 / C, Toyota TSC3500G, Toyota TSC3590G, Volvo EMC Requirements (1998)

Mobirise

Compact SIMULATOR

We can also perform EMC Pre-Compliance tests with the AMETEK Compact NX5 simulator, such as EFT/BURST, SURGE and POWER FAIL.
For tests according to ECE-R10, EN 300329, EN 300340,
EN 300342-1, EN 300386 V1.3.2, EN 301489-1, EN 301489-17, EN 301489-24,
EN 301489-7, EN 50121, EN 55024, EN 61000-4-11, EN 61000-4-29,
EN 61000-4-4, EN 61000-4-5, EN 61000-4-8, EN 61000-4-9, EN 61000-6-1,
EN 61000-6-2, FCC 97-270 (part 68) , IEC 60255-22-5, IEC 61000-4-11,
IEC 61000-4-29, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-,
IEC 61000-4-9, IEC 61326, IEC 61850-3, ITU-T K.20, ITU-T K.21, ITU-T K.41,
ITU-T K.45.

Mobirise

Conducted EMISSIONS

With the R&S tool HM6050-2 Line Impedance Stabilization Network we carry out emissions tests conducted from 10kHz to 30MHz, based on the VDE 0876 and CISPR Publ standards. 16 standards.

Mobirise

Radiated EMISSIONS

In the laboratory, we have a system for the measurement of radiated emissions composed of a TEM Cell and a Tektronix RSA306B spectrum analyzer with a frequency range from 9kHz to 6.2GHz, 40MHz band and a dynamic range from -160dBm to + 20dBm.
Using SignalVu-PC and EMCVu software we can perform tests of real-time EMC pre-compliance in accordance with FCC regulations, MIL-STD, DEF-STAN and CISPR, such as: CISPR 11, CISPR 12, CISPR 13, CISPR 14-1, CISPR 15, CISPR 22, CISPR 25, CISPR 32, EN 55011, EN 55012, EN 55014-1, EN 55015, EN 55022, EN 55025,
EN 55032, CFR Title 47 Part 15, CFR Title 47 Part 18.

Mobirise

Thermal Camera ANALYSIS

Through the thermo camera we can analyze, without contact, the temperature and heat distribution of the electronic boards with the aim of improving reliability.
It can be used to identify faulty components present on a non-functioning board.
In fact, thermography can detect hot spots, allowing better thermal management and excellent advantages in the design of printed circuits.

Mobirise

Electric SAFETY

With the SCHLEICH GLP2-ce BASIC tester we have the possibility to perform electrical safety tests. The standard "all in one" instrument for HVAC, HVDC, ISO, PE and leakage current tests.
- Earth resistance measurement up to 30A
- Insulation resistance measurement up to 6kV
- AC rigidity meters up to 6kV
- DC rigidity meters up to 6kV
- Functional tests up to 16A
